DZLG-Ribbon Conical Vacuum Dryer

Conical Vacuum Dryer with Hollow Ribbon Technology

With its jacketed vessel and hollow ribbon design, the Conical Vacuum Dryer provides a large heating surface plus efficient material loading and smooth discharge with no dead angles. The ribbon drives mixing for combined heating and blending. It is ideal for low-temperature vacuum operation, making it suitable for handling explosive and heat-sensitive materials.

Input: Loose powdery, granular solids
Output: Powder with 3%–5% moisture content
Temperature: Heat source temperature < 200°C
Additional Feature: Stirring and mixing

f 𝕏 in

A Ribbon Conical Vacuum Dryer for Dead-Angle-Free Drying

SINOTHERMO's ribbon conical vacuum dryer combines a jacketed conical vessel with a hollow ribbon agitator to heat, stir and dry powders and granules under vacuum. The conical shape allows smooth loading and discharge with no dead corners, while the ribbon continuously turns the batch for even drying at low temperature, suiting explosive and heat-sensitive materials.

A heated hollow ribbon both stirs the batch and adds conduction surface, combining mixing and drying in the same motion.
The cone geometry has no internal corners, so material loads evenly and discharges cleanly without residue pockets.
Vacuum lowers the evaporation point, allowing drying at a heat source below 200°C, suitable for heat-sensitive powders.
The sealed, low-oxygen vacuum environment is suited to explosive and easily oxidized solids that cannot be dried in open air.
Ongoing ribbon agitation keeps the bed moving during drying, helping reach a uniform 3–5% final moisture content.
