XSG-Spin Flash Dryer
Cyclonic, Fluidizing, Pneumatic and Grinding — Integrated
Combining fluidizing, pneumatic conveying and grinding in one unit, this innovative dryer surpasses conventional air dryers. Compact and efficient, it is built for productivity with seamless operation, and guarantees top-notch products by minimizing the material's exposure time.
- Input
- Loose, granular, or filter-cake solids
- Output
- Powder
- Temperature
- 140°C to 220°C (standard); below 140°C (heat-sensitive materials)
- Additional Feature
- Grinding
A Spin Flash Dryer That Dries and Grinds in One Pass
SINOTHERMO's spin flash dryer — a rotary flash dryer that combines pneumatic conveying, fluidization and grinding — turns loose solids, granules and wet filter cakes directly into fine powder. Hot air suspends and swirls the material while a rotor breaks up lumps, giving fast, uniform drying for chemical, mineral and food producers who need short residence times.
- Integrated fluidizing, pneumatic conveying and grinding replace a separate dryer plus mill, drying and de-lumping wet cakes into free-flowing powder in a single unit.
- Material is exposed to heat for only seconds, protecting color, activity and structure — with a below-140°C mode for heat-sensitive products.
- The rotor and swirling airflow disperse pasty, cohesive filter-cake feeds that clog conventional flash and air dryers.
- Simultaneous grinding produces fine, consistent powder directly, removing a downstream milling step for many materials.
- A small footprint and steady 140–220°C continuous operation deliver high throughput with straightforward, stable control.
Model
| Model | Cylinder Diameter (mm) | Main Unit Dimensions (mm) | Main Unit Power (kW) | Processing Air Volume (m³/h) | Evaporation Capacity (kg/h) |
|---|---|---|---|---|---|
| XSG-200 | 200 | 250 x 3000 | 5～9 | 300～800 | 10～20 |
| XSG-300 | 300 | 400 x 4500 | 8～15 | 600～1500 | 20～50 |
| XSG-400 | 400 | 500 x 5000 | 10～17.5 | 1250～2500 | 25～70 |
| XSG-500 | 500 | 600 x 5500 | 12～24 | 1500～4000 | 30～100 |
| XSG-600 | 600 | 700 x 5500 | 20～29 | 2500～5000 | 40～200 |
| XSG-800 | 800 | 900 x 6500 | 24～35 | 3000～8000 | 60～600 |
| XSG-1000 | 1000 | 1100 x 6800 | 40～62 | 5000～12500 | 100～1000 |
| XSG-1200 | 1200 | 1300 x 7000 | 50～89 | 10000～20000 | 150～1300 |
| XSG-1400 | 1400 | 1500 x 7000 | 60～105 | 14000～27000 | 200～1600 |
| XSG-1600 | 1600 | 1700 x 7500 | 70～135 | 18700～36000 | 250～2000 |
| XSG-1800 | 1800 | 2000 x 8000 | 100～180 | 30000～40000 | 300～2500 |
| XSG-2000 | 2000 | 2200 x 9000 | 150～200 | 35000～45000 | 400～3000 |
Applications
Chemical
Dries and grinds chemical filter cakes, salts and intermediates into uniform powder in one continuous pass.
Pigments & Dyes
Rapidly dries pigment and dye filter cakes while breaking up lumps for fine, dispersible powder.
Ceramics
Processes ceramic and clay slurry cakes into dry powder ready for downstream forming.
China Clay & Kaolin
Dries kaolin and mineral filter cakes with short exposure to preserve fineness and whiteness.
Metallurgy
Dries metal salts, hydroxides and mineral concentrates into free-flowing powders.
Environment
Reduces sludge and wastewater filter cakes to dry powder, cutting volume for handling or reuse.
Food Flavors & Fragrances
Gently dries heat-sensitive food and starch cakes below 140°C to protect quality.
Resins
Dries and de-lumps resin and polymer powders where short heat contact prevents degradation.
