LPG-Centrifugal Spray Dryer
Advanced Liquid-to-Powder Process
At the heart of our process, a high-speed centrifugal atomizer at the tower's peak transforms materials into super fine liquid drops. These liquid drops dry quickly upon contact with hot air, making the centrifugal spray dryer perfect for precise particle size, moisture, density and shape standards.
- Input
- Solutions, Emulsions, Suspensions
- Output
- Powder with 3%–5% moisture content
- Temperature
- Inlet air temperature range of 150°C to 500°C
Efficient Spray Drying with Centrifugal Technology
The Centrifugal Spray Dryer provides drying and precise control for a variety of materials, including those sensitive to heat. Its advanced technology enhances efficiency and quality while maintaining consistency. By regulating temperature and flow rates it produces high-quality spray-dried powder, efficiently reduces energy consumption and caters to multiple industries.
- Swift drying technology ensures production of spray-dried powder, reducing processing time significantly.
- Precise management of temperature and flow in spray drying delivers accuracy for optimal outcomes.
- Ideal for heat-sensitive materials, preserving integrity and quality throughout the drying process.
- Greatly improves production efficiency, allowing for faster turnaround times and reduced operational expenses.
- Guarantees the quality and consistency of spray-dried products, consistently meeting industry standards.
Model
| Model | LPG-5 | LPG-25 | LPG-50 | LPG-150 | LPG-200-2000 |
|---|---|---|---|---|---|
| Inlet Temperature | 140-350 Self-control | 140-350 Self-control | 140-350 Self-control | 140-350 Self-control | 140-350 Self-control |
| Outlet Temperature | 80-90 | 80-90 | 80-90 | 80-90 | 80-90 |
| Max. Moisture Evaporation (kg/h) | 5 | 25 | 50 | 150 | 200-2000 |
| Centrifugal Atomizer Drive Type | Compressed Air Drive | Compressed Air Drive | Mechanical Drive | Mechanical Drive | Mechanical Drive |
| Max. Speed (r.p.m) | 25000 | 18000 | 18000 | 15000 | 8000-15000 |
| Spray Disc Diameter (mm) | 50 | 120 | 120 | 150 | 180-240 |
| Heat Source | Electric | Steam + Electric | Steam + Electric, Fuel Oil, Gas, Hot Air Furnace | Steam + Electric, Fuel Oil, Gas, Hot Air Furnace | Steam + Electric, Fuel Oil, Gas, Hot Air Furnace |
| Max. Electric Heating Power (kW) | 9 | 36 | 72 | 99 | N/A |
| External Dimensions (L × W × H) (m) | 1.8×0.93×2.2 | 3×2.7×4.26 | 3.5×3.5×4.8 | 5.5×4×7 | Determined by actual situation |
| Dry Powder Recovery (%) | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 |
- Moisture evaporation capacity depends on material characteristics and inlet/outlet air temperature.
- Parameters are subject to change as products are continuously updated.
Applications
Cosmetics
High-speed drying of cosmetic ingredients like powders and extracts, ensuring product quality with spray drying.
Pharmaceutical
Employing spray drying ensures the stability of active ingredients and is ideal for high-efficiency drug manufacturing.
Food
Perfect for drying food ingredients like milk powder while maintaining their nutritional value and flavor.
Biotechnology
Utilizes spray drying for bioproducts such as enzymes and proteins to maintain their activity.
Chemical
Efficiently dries chemicals to ensure the safety and quality of chemical products using spray drying technology.
Agriculture
Employed for drying items like grains and plant extracts, maintaining their innate features.
Environment
Using spray drying to treat sludge and wastewater helps decrease waste volume and enhance processing efficiency.
Ceramic
Perfect for drying ceramic powders to enhance the quality of finished products through innovative spray drying.
