ZLPG-Extract Spray Dryer

ZLPG-Extract Spray Dryer

Specialized Spray Dryer for Extracts

The Extract Spray Dryer features a cylinder equipped with a cooling system specifically designed for drying extracts while keeping wall temperatures below 80°C. It includes an airbrush that cleans the walls during operation to prevent adhesion and protect the powder from burning.

Input
Extracts (Liquid)
Output
Extracts (Powder) with 3%–8% moisture content
Temperature
Inlet air temperature range of 140°C to 180°C
Additional Features
Freeze dehumidification, Air brush for tower cleaning
Request A Quote

An Extract Spray Dryer with Cooled Tower Walls

SINOTHERMO's extract spray dryer is built specifically for drying liquid extracts into powder, using a cylinder cooling system that holds tower wall temperatures below 80°C. An airbrush system cleans the walls during operation to stop extract residue from sticking and scorching, protecting the finished powder's quality.

  • A dedicated cylinder cooling system keeps wall temperatures below 80°C, reducing the risk of extract residue burning against the hot surface.
  • An airbrush system continuously cleans the tower interior during operation, preventing sticky extract buildup and product loss.
  • Freeze dehumidification manages moisture in the drying air, supporting stable operation with sticky, hygroscopic extract feeds.
  • Operates at a 140–180°C inlet air range, suited to converting extract liquids into powder without the higher temperatures used for less sensitive feeds.
  • Delivers extract powder at a controlled 3–8% moisture content for stable storage and downstream formulation.
An Extract Spray Dryer with Cooled Tower Walls

Applications

Agriculture & Herbal

Agriculture & Herbal

Converts herbal and botanical liquid extracts into powder while protecting active compounds from wall-surface burning.

Food Flavors & Fragrances

Food Flavors & Fragrances

Spray-dries food and flavor extracts into powder with reduced risk of scorching on tower walls.

Pharmaceutical

Pharmaceutical

Dries extract-based active ingredients into powder under controlled, cooled-wall conditions.

Biotechnology

Biotechnology

Suited to bio-based extract liquids that are prone to sticking or degrading against hot surfaces.

Cosmetics

Cosmetics

Converts cosmetic active extracts into powder form for formulation.

Services

→Learn more about Services
  • 1Pre-Sales Testing and Experiment
  • 2Professional Customization Design
  • 3On-site Installation and Commissioning
  • 4Training and Technical Support
  • 5Full Life Circle Maintenance and After-sales
SINOTHERMO services

Frequently Asked Questions

What is an extract spray dryer?

A spray dryer built specifically for drying liquid extracts into powder. SINOTHERMO's ZLPG has a cylinder cooling system that keeps the tower wall temperature below 80 °C, and an airbrush that cleans the walls during operation.

Why is wall temperature important when drying extracts?

Extracts tend to stick to hot tower walls and scorch. Keeping the wall below 80 °C reduces the risk of residue burning against the surface, and the airbrush cleans the walls while the dryer runs to prevent buildup and product loss.

What extracts can the ZLPG dry?

Liquid extracts. SINOTHERMO lists uses with herbal and botanical extracts, food and flavor extracts, extract-based active ingredients, bio-based extract liquids and cosmetic active extracts.

What temperatures and moisture content does the ZLPG reach?

Inlet air temperature ranges from 140 °C to 180 °C, and the extract powder leaves at 3%-8% moisture content.

How does the ZLPG handle sticky or hygroscopic extracts?

Through cooled tower walls, the airbrush cleaning system and freeze dehumidification, which manages moisture in the drying air and supports stable operation with sticky, hygroscopic extract feeds.

Can I test my material before buying?

Yes. Bring your material to SINOTHERMO's testing lab and our engineers will run it on pilot-scale equipment, so you can see the result before you invest.
