PGL-Fluidized Bed Spray Granulator

Combines Mixing, Granulating and Drying for High-Excipient Granulation

Excipient-rich granulation finds an ideal match in this unit. Excipients in the hopper form a fluidized bed that acts as seeds or carriers, while the main material — typically a liquid extract making up a smaller proportion of the batch — is sprayed from above and merges at the bed's edge for granulation. This method is particularly suited to heat-sensitive materials.

Input: Carrier materials in powder form, main material in liquid form
Output: Solid medium-sized granules, 3%–5% moisture content
Type: Spray Fluidized Bed, Wet Granulation
Additional Features: Mixing, Drying, Cooling

f 𝕏 in

A Fluidized Bed Spray Granulator for High-Excipient, Heat-Sensitive Granulation

SINOTHERMO's fluidized bed spray granulator loads carrier or excipient powder into the hopper to form a fluidized bed, while the main material — typically a liquid extract making up a smaller proportion of the batch — is sprayed from above and merges with the carrier particles at the bed's edge. This carrier-based approach suits high-excipient formulations and heat-sensitive main ingredients.

Excipient or carrier powder forms the fluidized bed itself, acting as seed particles that the sprayed liquid material builds onto.
The main material, in liquid form and typically a smaller proportion of the batch, is sprayed onto the fluidized carrier bed rather than fed as a bulk powder.
Sprayed liquid merges with carrier particles at the bed's edge, distributing the main material across the granule population.
The carrier-based, low-temperature approach is well suited to liquid extracts and other main materials that would degrade under higher-temperature processing.
Mixing, drying and cooling take place in the same fluidized bed, producing solid granules at 3–5% moisture without a separate transfer step.
