Industrial Dryer and Pilot Dryer
SINOTHERMO's industrial and pilot dryers span two core drying technologies — conduction (vacuum) and convection (hot-air) — covering everything from heat-sensitive vacuum drying to high-throughput continuous production.
CD Dryer
Categories: Conduction and Vacuum Dryer
Continuous Drying for Liquid and Paste-like Materials:
The CD Dryer is designed for continuous drying of liquids and pastes. Utilizing indirectly heated discs, the dryer efficiently transfers heat to the material, creating a thin layer for rapid evaporation. This method ensures effective drying and consistent product quality.
- Input:
- Liquid and Pasty Materials
- Output:
- Dried Solids (flake or powder, depending on application)
- Heat Transfer Coefficient:
- Overall heat transfer coefficient: 2,300W/m²k
- Thermal Efficiency:
- 80 to 85% thermal efficiency
LPG-Centrifugal Spray Dryer
Categories: Convection Dryer, Spray Dryer
Advanced Liquid-to-Powder Process:
A high-speed centrifugal atomizer at the tower's peak transforms materials into super fine liquid drops that dry quickly upon contact with hot air — perfect for precise particle size, moisture, density and shape standards.
- Input:
- Solutions, Emulsions, Suspensions
- Output:
- Powder with 3%-5% moisture content
- Temperature:
- Inlet air temperature range of 150°C to 500°C
YPG-Pressure Spray Dryer
Categories: Convection Dryer, Spray Dryer
High-Pressure Nozzle Atomization:
The Pressure Spray Dryer atomizes feed liquid through high-pressure nozzles, producing coarser and denser granules with excellent flowability — widely used for foods, chemicals and dairy powders.
- Input:
- Solutions, Emulsions, Suspensions
- Output:
- Coarse powder or granules with 3%-5% moisture content
- Temperature:
- Inlet air temperature range of 150°C to 350°C
CTC-Tray Dryer
Categories: Convection Dryer
Hot Air Circulation Batch Drying:
The Hot Air Circulation Tray Dryer warms materials evenly on trays with forced hot-air circulation. Simple, reliable batch drying for granules, powders, herbs and food ingredients.
- Input:
- Granules, Powders, Herbs, Sliced Materials
- Output:
- Dried solids with uniform moisture content
- Temperature:
- Hot air temperature ≤140°C
XSG-Spin Flash Dryer
Categories: Convection Dryer, Flash Dryer
One-Step Continuous Flash Drying:
The Spin Flash Dryer dries pastes and filter cakes in a single continuous step. Hot air and mechanical agitation break up material while drying — no pre-crushing needed.
- Input:
- Pastes, Filter Cakes, Thick Slurries
- Output:
- Powder with 3%-8% moisture content
- Temperature:
- Inlet air temperature range of 150°C to 350°C
ZPG-Vacuum Rake Dryer
Categories: Conduction and Vacuum Dryer
Rake Agitator Vacuum Conduction Dryer:
The Rake Dryer comes with a large-area jacket heating system and a rake agitator that increases the heating surface area, making it easier to move and heat materials. Operating under vacuum, it is perfect for handling flammable, organic solvent-based and heat-sensitive materials.
- Input:
- Pastes, Slurries, Viscous Materials
- Output:
- Powder with 3%-8% moisture content
- Temperature:
- Heat source temperature <150°C
KJG-Vacuum Paddle Dryer
Categories: Conduction and Vacuum Dryer
Vacuum Conduction Dryer with Hollow Paddle Agitator:
With its heating surface and wedge-shaped hollow paddle agitators, the Vacuum Paddle Dryer outperforms conventional rake vacuum dryers in heating effectiveness. It aids in the movement and heating of materials under vacuum, suitable for flammable, explosive, organic solvent-based and heat-sensitive materials.
- Input:
- Liquids, Slurries, Pastes, Mashes
- Output:
- Powder with 3%-10% moisture content
- Temperature:
- Heat source temperature range of 50°C to 200°C
- Additional Feature:
- Mixing, Mild Crushing
PLG-Vacuum Vertical Plate Dryer
Categories: Conduction and Vacuum Dryer
Effective Continuous Vacuum Conduction Dryer:
The Vacuum Plate Dryer incorporates discs for efficient heating, providing a generous heating surface in a compact layout. It excels in vacuum operations, ideal for managing flammable, explosive and heat-sensitive materials.
- Input:
- Loose powder, Granules
- Output:
- Powder, Granules with 3%-8% moisture content
- Temperature:
- Heat source temperature <200°C
FZG-Static Vacuum Cabinet Dryer
Categories: Conduction and Vacuum Dryer, Vacuum Tray Dryer
Vacuum Dryer with Pulse Back-Blow Function:
The Square Static Vacuum Dryer comes with spacious hollow heating tubes, warming materials on trays. It is perfect for operating at low temperatures in a vacuum, suitable for handling explosive and heat-sensitive materials while maintaining their original characteristics and properties.
- Input:
- Liquids, Slurries, Pastes and Thick Materials
- Output:
- Lump Solids with 3%-5% moisture content
- Temperature:
- Heat source temperature <100°C
SZG-Double Cone Rotary Vacuum Dryer
Categories: Conduction and Vacuum Dryer
Dependable Vacuum Conduction Drying Solution:
The Double Cone Rotary Vacuum Dryer includes a heating system and an interior free of dead angles, making it highly adaptable. With its barrel rotation it effectively blends the contents — suitable for low-temperature vacuum operation with organic solvent-based and heat-sensitive materials.
- Input:
- Powders, Granules
- Output:
- Powder with 3%-5% moisture content
- Temperature:
- Heat source temperature <150°C
- Additional Feature:
- Rotating blending
DZLG-Ribbon Conical Vacuum Dryer
Categories: Conduction and Vacuum Dryer
Conical Vacuum Dryer with Hollow Ribbon Technology:
With its jacket and ribbon design, the Conical Vacuum Dryer provides a large heating surface, efficient material loading and smooth discharge without any dead angles. The ribbon facilitates mixing for heating and blending — perfect for low-temperature vacuum conditions with explosive and heat-sensitive materials.
- Input:
- Loose powdery, granular solids
- Output:
- Powder with 3%-5% moisture content
- Temperature:
- Heat source temperature <200°C
- Additional Feature:
- Stirring and mixing
DW-Belt Dryer
Categories: Convection Dryer
Continuous Convection Dryer with Mesh Belt:
The Belt Dryer can be configured with single or multiple mesh-belt layers, spreading material evenly for directional hot-air drying. Belt speed adjusts to each material's temperature and moisture content, so it runs at comparatively low temperatures while continuously processing large batches.
- Input:
- Permeable solids in sheets, strips, granules or blocks
- Output:
- Sheet, strip, granule or block solids with 3%–8% moisture content
- Temperature:
- Inlet air temperature < 200°C
- Additional Feature:
- Cooling
ZLG-Horizontal Vibrating Fluidized Bed Dryer
Categories: Convection Dryer, Fluidized Bed Dryer, Vibrating Dryer
Continuous Drying Solution for Granular Materials:
Operating on the principle of fluidization combined with vibration, the Vibrating Fluid Bed Dryer processes granules by circulating them on heated air that dries them evenly. This approach minimizes surface damage, prevents pollution thanks to its enclosed design, and gives granules time to settle — facilitating stable, continuous production.
- Input:
- Granules with moisture content < 20%
- Output:
- Granules with 1%–5% moisture content
- Temperature:
- Inlet air temperature < 200°C
- Additional Feature:
- Cooling
HZG-Rotary Kiln
Categories: Convection Dryer
Perfect for Large-Scale, Continuous Drying:
Wet material enters at one end of the Rotary Kiln, where internal flights agitate it and blend it thoroughly with hot air. This elongated drum dryer, spanning many metres, can process hundreds of tons per hour, and its drum speed adjusts from 1 to 10 RPM to suit different requirements.
- Input:
- Granular materials
- Output:
- Granules with 3%–5% moisture content
- Temperature:
- Inlet air temperature range of 40°C to 350°C
- Additional Feature:
- Mixing
HG/GT-Vacuum Drum Scraper Dryer
Categories: Conduction and Vacuum Dryer
Continuous Drying for Paste-like Materials:
In operation, the rotating drum picks up material as a thin film. Heat transfers from the inner to the outer wall, effectively evaporating moisture, while an internal scraper continuously converts the dried film into flake-like product in a short time.
- Input:
- Pasty, Viscous and Thick Materials
- Output:
- Flake-like Solids with 5%–8% moisture content
- Temperature:
- Inlet air temperature range of 120°C to 260°C
- Additional Feature:
- Cooling
GXP-Closed Circulation Spray Dryer
Categories: Convection Dryer, Spray Dryer
Optimal Drying for Sensitive Materials:
This explosion-proof spray dryer operates in a sealed environment, using inert gas as the drying medium to fully recover solvents from raw materials. The recyclable drying medium provides superior protection for sensitive materials.
- Input:
- Solutions, Emulsions, Suspensions
- Output:
- Powder with 3%–8% moisture content
- Temperature:
- Inlet air temperature range of 100°C to 300°C
- Suitability:
- Anaerobic, explosion-proof and low-temperature conditions
ZLPG-Extract Spray Dryer
Categories: Convection Dryer, Spray Dryer
Specialized Spray Dryer for Extracts:
The Extract Spray Dryer features a cylinder equipped with a cooling system specifically designed for drying extracts while keeping wall temperatures below 80°C. It includes an airbrush that cleans the walls during operation to prevent adhesion and protect the powder from burning.
- Input:
- Extracts (Liquid)
- Output:
- Extracts (Powder) with 3%–8% moisture content
- Temperature:
- Inlet air temperature range of 140°C to 180°C
- Additional Features:
- Freeze dehumidification, Air brush for tower cleaning
Pneumatic Flash Dryer
Categories: Convection Dryer, Flash Dryer
Integrated Handling for Heat-Sensitive, Loose Solid Materials:
Designed for temperature-sensitive and slightly viscous materials, this equipment offers a wide range of uses for loose solid materials. Its modular design allows drying and grinding stages to be added to meet varying customer requirements.
- Input:
- Non-viscous, loose solid materials
- Output:
- Powder, granules, with 3%–6% moisture content
- Temperature:
- Inlet temperature < 200°C
- Additional Feature:
- Grinding
FG-Vertical Fluidized Bed Dryer
Categories: Convection Dryer, Fluidized Bed Dryer
Solution for Batch Drying of Granules and Powder:
The Vertical Fluid Bed Dryer fluidizes materials with an upward air stream that promotes contact for quick drying or cooling. Designed specifically for batch production, it allows taller bed heights than horizontal fluidized bed dryers and is commonly paired with wet granulation machines.
- Input:
- Powders and Granules, moisture < 20%
- Output:
- Powders and Granules, moisture 3%–5%
- Temperature:
- Inlet air temperature < 100°C
- Additional Feature:
- Convertible to a spray fluidized bed granulator
XF-Horizontal Fluidized Bed Dryer
Categories: Convection Dryer, Fluidized Bed Dryer
Versatile Continuous Drying for Granules and Powder:
The Horizontal Fluidized Bed Dryer aerates damp materials with an upward air stream to dry or cool them. Built for continuous manufacturing, it offers residence times from a few seconds to minutes, ensuring effective processing.
- Input:
- Powders and Granules, moisture < 20%
- Output:
- Powders and Granules, moisture 3%–5%
- Temperature:
- Inlet air temperature < 100°C
- Additional Feature:
- Cooling
GFG-Vertical Blending Fluidized Bed Dryer
Categories: Convection Dryer, Fluidized Bed Dryer
Fluidized Bed Drying with Built-In Mixing:
The Vertical Blending Fluidized Bed Dryer is equipped with a mixing mechanism that helps form a fluidized bed inside the vessel when handling heavy loads. Ideal for mass production, it can process thick materials and is typically paired with wet granulation setups.
- Input:
- Powder and Granules, moisture < 20%
- Output:
- Powder and Granules, moisture 3%–5%
- Temperature:
- Inlet air temperature < 100°C
- Additional Feature:
- Stirring, Cooling
LZG-Spiral Vibrating Dryer
Categories: Convection Dryer, Vibrating Dryer
Method for Drying Pellets and Granules:
The Spiral Vibrating Dryer dries materials by using centrifugal vibration and gravity to move them in a bouncing path from top to bottom along a spiral bed. Fresh hot air enters from below, interacting thoroughly with the material for heat and mass transfer before leaving through the top — ensuring even drying.
- Input:
- Granular, short-rod and spherical solids with < 20% moisture
- Output:
- Granules, short rods and spheres with 3%–5% moisture
- Temperature:
- Inlet air temperature < 100°C
- Additional Feature:
- Cooling
ZYG-Vacuum Horizontal Disc Dryer
Categories: Conduction and Vacuum Dryer
Vacuum Conduction Dryer with Hollow Disc Stirrers:
The Vacuum Horizontal Disc Dryer has a large-area jacket for heating and hollow disc stirrers that enhance the heating surface. It performs better than rake and paddle vacuum dryers in heating efficiency for many materials, is suited to low-temperature vacuum operation, and is ideal for handling flammable, explosive, organic-solvent-based and heat-sensitive materials.
- Input:
- Liquids, Slurries, Pastes, and Mashes
- Output:
- Powder with 3%–10% moisture content
- Temperature:
- Heat source temperature 50°C to 200°C
- Additional Feature:
- Stirring, Mild Crushing
